Technical Specifications
| Model | HSS-200 |
| Jumbo Roll Width | Max. 450 mm |
| Jumbo Roll Diameter | Max. 800 mm |
| Jumbo Roll Core ID | 76 mm |
| Finished Roll Width | Max. 450 mm |
| Finished Roll Diameter | Max. 110 mm |
| Finished Roll Core ID | 20 - 50 mm (Thickness > 2mm) |
| Mechanical Speed | Max. 450 m/min |
| Main Motor Power | 4 KW (3-Phase 380V, 50Hz) |
| Inverter Brand | Delta (Taiwan) |
| PLC Brand | Siemens (Germany) |
| Touch Screen (HMI) | WeinView 7" |
| Wall Plate Thickness | 20 mm |
| Machine Dimensions | 1640 × 1250 × 1000 mm |
| Weight | 750 KGS |
Product Description
Product Overview: Cost-Effective High-Speed Rewinding
The HSS-200 Semi-Automatic Aluminum Foil Rewinding Machine is engineered for manufacturers who need a balance between high production speed and operational flexibility. Unlike fully automatic lines, this machine utilizes a semi-automatic turret design, allowing for manual core loading while maintaining a high mechanical speed of up to 450 meters per minute. It is built with a heavy-duty 20mm thick wall plate structure to ensure stability and vibration-free operation even at top speeds.
Key Features & Brand Components
- Advanced Control System: The machine is powered by a reliable Siemens PLC (Germany) and operated via a user-friendly 7-inch WeinView Touch Screen. This allows for easy parameter setting and monitoring.
- Precision Drive & Tension: It employs a Delta Inverter (4KW) and Delta Servo Motor for the turnover mechanism, ensuring smooth acceleration and precise tension control during the rewinding process.
- Accurate Meter Counting: Integrated with a high-precision Omron Encoder (Japan) for exact length measurement, minimizing material waste.
- Versatile Compatibility: Designed to handle jumbo rolls up to 800mm in diameter and 450mm in width. It effectively rewinds aluminum foil, silicon paper, and baking paper into finished consumer rolls.
- Robust Build Quality: Features top-tier electrical components including Schneider switches (France) and a solid steel frame structure, guaranteeing a long service life.
Ideal Applications
The HSS-200 is suitable for converting:
- Kitchen Foil: Standard household aluminum foil rolls.
- Catering Foil: Longer rolls for food service applications.
- Baking Paper: Silicon-coated paper for ovens and cooking.
Get a Quote: Reliable performance at a competitive price. Contact Newtop Machinery for the HSS-200 pricing.
Product Video
FAQ: HSS-200 Semi-Automatic Aluminum Foil Rewinding Machine
The HSS-200 is a semi-automatic machine, meaning the operator manually loads the paper cores onto the shaft. However, it still offers high-speed rewinding (450m/min) and automatic meter counting. It is a more cost-effective solution for small-to-medium production runs compared to fully automatic lines that include auto-loaders and gluers.
It is designed primarily for Aluminum Foil but is also capable of rewinding Baking Paper and Silicon Paper. The machine's tension control system ensures it handles these different materials without tearing or wrinkling.
The HSS-200 can handle large jumbo rolls with a maximum diameter of 800mm and a maximum width of 450mm. The standard core ID for the jumbo roll is 76mm.
