Technical Specifications
| Model | NTP-700B |
| Control System | 6-Axis Servo Motor Linkage Control |
| Max. Forming Area | 320 × 680 mm |
| Max. Forming Depth | 170 mm |
| Sheet Thickness | 0.2 - 2.5 mm |
| Max. Sheet Width | 820 mm |
| Max. Speed | 42 cycles/min |
| Suitable Materials | PP, PS, HIPS, PVC, PET, PLA, PC |
| Heating Power | 150 kW |
| Total Power | 180 kW (Installed) / 50 kW (Running) |
| Power Supply | 3-Phase 4-Wire AC380V ±15V |
| Machine Weight | 16 Tons |
Product Description
Product Overview: The Apex of Thermoforming Technology
The NTP-700B Plastic Cup Thermoforming Machine represents the world's most advanced solution for high-volume plastic container production. Integrating mechanical, electrical, and pneumatic systems, this machine features a state-of-the-art 6-Axis Servo Motor Linkage Control System. Unlike traditional cam-driven machines, the NTP-700B offers unparalleled precision and coordination, capable of reaching speeds up to 42 cycles per minute. It is the specialist choice for producing high-quality disposable cups, jelly cups, and bowls using PP, PS, HIPS, PVC, PET, and Biodegradable PLA sheets.
Key Features & 6-Axis Servo Advantage
- 6-Axis Servo Orchestration: The core movements—including sheet feeding, plug assist, forming, and stacking—are driven by 6 independent servo motors. This ensures perfectly synchronized joint movements for smoother operation and higher energy efficiency.
- Pressure Forming Technology: Combines vacuum and pressure to form cups with sharper definition and uniform wall thickness, essential for high-quality retail packaging.
- Advanced "V" Type Stacker: The cup stacking unit is also driven by a servo motor. The "V" design ensures stable, automatic counting and stacking of cups, delivering them ready for packing without manual intervention.
- German Heating System: Equipped with premium German heaters with precise segment control. This ensures uniform temperature distribution across the sheet, which is critical when processing sensitive materials like PLA.
- Full Production Line Integration: The NTP-700B is designed to connect seamlessly with downstream equipment such as Curling Machines, Cup Printing Machines, and Automatic Packing Machines for a fully automated factory line.
Ideal Applications
The NTP-700B is engineered for mass production of:
- Beverage Cups: Water cups, Coffee cups, Bubble tea cups (PP/PET).
- Dairy Packaging: Yogurt cups, Ice cream cups, Jelly cups.
- Eco-Friendly Packaging: PLA biodegradable cups and bowls.
Invest in High Speed: Ready to upgrade your output to 42 cycles/minute? Contact Newtop Machinery for a technical proposal on the NTP-700B.
